Searchlight &Broadcasting System LP12

    Product Introduction

    The LP12 is a searchlight and broadcasting integrated payload designed specifically for the DJI M30 enterprise drone model. With its streamline design, it pushes the limits of product performance while taking characterized appearance into account, and effectively reduces wind resistance and improves the duration of flight. The LP12 is the most efficient lighting and broadcasting payload product of czi so far, combining the imaging optics of the Gimbal Light Series, with the LRAD long distance broadcasting technology of the Mega Phone Series, extremely light weight and small size. Weighing only 270g, it has an effective illumination distance up to 100m and an effective broadcasting distance of 200m, which can meet the operational needs of security patrols and outdoor search and rescue scenarios. The LP12 is deeply integrated with the DJI Pilot APP, allowing quick access to all broadcast and light functions, making it more convenient to operate.

    Product images

    ad5a19a69c873d15ef6ca2b1dac7e5f468c2ae017fe3feabcc1b70a4250fe7

    Specifications

    Electrical interface DJI PSDK
    Weight 288g (without quick-mount fixture)
    306g (with quick-mount fixture)
    Dimensions 156*109*84mm
    Searchlight power Regular mode:30w
    Ultra bright mode&Flashing mode:40w
    Speaker power 15W
    Power supply voltage 24V
    Luminous flux 2122±3%lm
    Searchlight FOV 13°
    Spot diameter 34m(distance:150m)
    22.8m(distance:100m)
    29.6m(distance:130m)
    11.4m(distance:50m)
    Illuminated area 102㎡(distance:50m)
    407㎡(distance:100m)
    688㎡(distance:130m)
    917㎡(distance:150m)
    Central illuminance 25Lux(distance:50m)
    6.3Lux(distance:100m)
    2.5Lux(distance:130m)
    1.7Lux(distance:150m)
    Gimbal movement range Pitch -120°~+45° (same as drone camera)
    Maximum sound pressure 122dB
    Effective broadcasting distance 200m@76db
    350m@69db
    Broadcasting method Live broadcasting
    Upload the recording files
    Play audio file
    Text To Speech (supports multi-language)
    Background sound
    Audio formats mp3/wav/m4a/flac/aac
    App support DJI Pilot/DJI Pilot2
    Operating temperature -20°C~+50°C
