UniDrone E900 multi-function logistic Drone

    Product Introduction

    UniDrone E900 has a maximum takeoff weight of 10.5kg and a maximum payload capacity of 2.1kg, offering enhanced payload capabilities. It supports third-party mounting and features dual expansion slots on the drone platform, allowing for various payloads such as gimbal cameras, loudspeakers, lighting equipment, and more.

    UniDrone E900 is equipped with a fully self-developed integrated industrial propulsion system, featuring an in-house designed FOC ESC and PWM +CAN dual-throttle redundancy.

    E900 utilizes a high-performance professional handheld ground station, offering an exceptional control experience through outstanding performance and innovative design. It takes drone operation to new heights, advancing

    The drone is equipped with an autopilot system featuring an H7 dual-precision floating-point processor. It uses built-in dual IMU redundancy and an internal shock-absorbing structure design, providing the aircraft with high reliability.

    UniDrone E900 is equipped with forward obstacle avoidance, capable of detecting obstacles within its path and avoiding them in a timely manner, further enhancing flight safety.
     E900 supports high-precision positioning across all systems and frequencies, including BeiDou, GPS, GLONASS, and Galileo. Equipped with a built-inRM3100 industrial-grade magnetometer and dual-antenna direction finding, it delivers exceptional anti-interference performance even in complex electromagnetic environments.

    UniDrone E900 is equipped with a 4K ultra-wideFPV camera, offering a seamless switch between the gimbal/pod view and the flight view, enhancing flight safety.

    The E900 is equipped with an intelligent Al tracking module.This enhances task execution efficiency and adapts to a wide range of mission requirements.

    Product images

    3-19

    Specifications

    Symmetrical motor wheelbase 900 mm
    Battery life 56 min(no load)
      43 min(full load)
    Chart transmission distance 35  square kilometre
    Maximum rise/fall speed 4 m/s (rising)    2 m/s (down)
    Remote control configuration 7 "1080P HD large screen 2.4G/5G dual band 1600 nits highlighted
    Communication frequency band 2.4G/5G dual band
    Grade Protection IPX4
    Maximum horizontal flight speed 20m/S
    Remote control life 8 hours of life PD 30W fast charge
    Load capacity 10.5kg (maximum take-off weight)
      2.1kg (maximum load weight)
    Power configuration 6.5kg single axis maximum tensile FOC electric control
    Positioning orientation accuracy RTK centimeter-level positioning orientation
    Body size Machine size (excluding pulp),L738*W673*H425mm
    Folding size L428*W412*H425mm
    Overall package size L700mm*W700mm*H400mm
    Machine weight (shipping form) 21.5kg (battery not included)
    Smart battery package size L275MM*150MM*H180(reference)
    Smart battery weight 3.77kg
